Zero Leakage Sealing: Metal-to-metal, cam-action sealing ensures tight shut-off even in high-temperature or high-pressure systems.
Long Service Life: Non-rubbing design minimizes wear, increasing the number of cycles without maintenance.
Fire-Safe Design: Engineered to maintain sealing integrity in fire scenarios; compliant with fire-safe standards.
Bi-directional Operation: Provides effective sealing in both flow directions.
Low Torque Operation: Efficient opening and closing with reduced actuator size and energy requirements.
Suitable for Harsh Media: Handles steam, gases, corrosive fluids, and abrasive slurries.
| Parameter | Specification |
|---|---|
| Function | On/Off or Throttling |
| Connection Type | Flanged, Lug, Wafer, Butt Weld |
| Material | Body: Carbon Steel, Stainless Steel, Duplex Steel, Alloy Steel Disc/Seat: Stellite, Inconel, 316SS, or custom alloys |
| Max. Nominal Pressure | Up to Class 600 / PN100 |
| Max. Nominal Size | Up to DN1600 (64") |
| Allowable Fluid Temperature | -196°C to +600°C (depending on materials) |
 | Applications
|
